QU-2-4K22 – 1 to 2 Full 4K HDMI Distribution Amplifier

HDMI 2.0, HDCP 2.2 and DVI compliant HDMI 1 to 2 splitter Supports UHDTV resolutions up to 4K2K: 3840×2160@24/25/30/50/60Hz & 4096×2160 @24/25/30/60Hz Supports passthrough of high definition audio: LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, DTS 2/5.1CH, Dolby TrueHD, DTS-HD Master Audio & Dolby Atmos Supports System Reset function (CEC active source command) allows the unit to reset the TV to its default HDMI input automatically HDMI input supports 'Standard' mode and 'TV' mode EDID settings Input and output status are indicated on the front panel HDMI with HDR 6G (HDR10/Dolby Vision support), 3D & 4K@60Hz support, DVI 1.0 compatible Supports current 10-bit and 12-bit HDR (High Dynamic Range) formats Automatic 4K to 1080p down-scaling and colour space conversion (4:4:4 to 4:2:0) for each independent output based on each connected display’s EDID  Independent HDCP management engine for each output ensures stable HDCP performance Controlled via front-panel switches Inputs  1x HDMI [1x HDMI Uncompressed AV and Data]1x USB 3 Type B [1x Service Port Power & Data] Outputs  2x HDMI [2x HDMI Uncompressed AV and Data] PSU 5V/2.6A Dimensions  128mm [W] x 25mm [H] x 108mm [D]  Net Weight  360g Gross Weight  660g Product Stock Category Core Product
