PU-1H3HBTE – 1 HDMI to 3 HDBaseT1 Splitter (100m) with HDMI bypass
$18.19
$33.11
Supports all v1.4 HDMI resolutions including 4K. HDMI, HDCP, & DVI compliant Supports HDMI / LAN / PoC (Power over Cable) / IR Supports resolutions VGA~WUXGA, 480i~1080p, 4K UHD@24/25/30Hz (RGB 4:4:4 & YUV 4:2:2), 4K UHD@ 60Hz (YUV 4:2:0), 4K/2K@24/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and 4K/2K@ 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings Supports uncompressed video/audio up to 10.2Gbps Supports HDCP repeating and CEC functions Additional HDMI bypass output provided to improve flexibility Supports 1080p distances up to 100 meters through CAT5e/6 cables Audio support up to 7.1CH & Dolby TrueHD, DTS-HD Supports 3D signals Supports 4K/2K & 4K UHD - CAT5e/6 = 70m & CAT6a/7 = 100m Inputs 1x HDMI [1x HDMI Uncompressed AV and Data]1x 3.5mm Stereo mini-jack [1x Infra Red Receiver]1x RJ45 [1x LAN Serving] Outputs 1x HDMI [1x HDMI Uncompressed AV and Data]3x RJ45 [3x HDMI & Propriety Data]1x 3.5mm Stereo mini-jack [1x Infra Red Emitter] PSU 24V/2.7A Dimensions 145mm [W] x 30mm [H] x 199mm [D] Net Weight 640g Gross Weight 1.66kg Product Stock Category Core Product
