PU-1H3HBTPL – 1 HDMI to 3 HDBaseT1 LITE Splitter (60m) with HDMI bypass
$28.05
$35.9
Supports all v1.4 HDMI resolutions plus 4K HDMI, HDCP, & DVI compliant Supports uncompressed video/audio up to 10.2Gbps Supports resolutions VGA~WUXGA, 480i~1080p, 4K UHD@24/25/30Hz (RGB 4:4:4 & YUV 4:2:2), 4K UHD@ 60Hz (YUV 4:2:0), 4K/2K@24/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and 4K/2K@ 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings Supports HDCP repeating and CEC functions Supports 1080p distances up to 60 meters through CAT5e/6 cables Audio support up to 7.1CH & Dolby TrueHD, DTS-HD Supports HDMI and IR Supports 3D signals Supports PoC (Power over Cable) providing power for the receivers Supports 4K/2K & 4K UHD - CAT5e/6 = 35m & CAT6a/7 = 40m Inputs 1x HDMI [1x HDMI Uncompressed AV and Data]1x 3.5mm Stereo mini-jack [1x Infra Red Receiver] Outputs 1x HDMI [1x HDMI Uncompressed AV and Data]3x RJ45 [3x HDBaseT Lite PoC HDMI & Propriety Data]1x 3.5mm Stereo mini-jack [1x Infra Red Emitter] PSU 24V/2.7A Dimensions 145mm [W] x 30mm [H] x 199mm [D] Net Weight 620g Gross Weight 1.66kg Product Stock Category Core Product
