PU-1H2HBTE – 1 HDMI to 2 HDBaseT1 Splitter (100m) with HDMI bypass
$20.68
$29.37
Supports all v1.4 HDMI resolutions plus 4K HDMI, HDCP, & DVI compliant Supports uncompressed video/audio up to 10.2Gbps Supports resolutions VGA~WUXGA, 480i~1080p, 4K UHD@24/25/30Hz (RGB 4:4:4 & YUV 4:2:2), 4K UHD@ 60Hz (YUV 4:2:0), 4K/2K@24/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and 4K/2K@ 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings Supports HDCP repeating and CEC functions Supports 1080p distances up to 100 meters through CAT5e/6 cables Audio support up to 7.1CH & Dolby TrueHD, DTS-HD Supports full 5-Play™ Convergence : HDMI / LAN / PoC (Power over Cable) / IR / RS-232 Supports 3D signals Supports 4K/2K & 4K UHD - CAT5e/6 = 70m & CAT6a/7 = 100m Inputs 1x HDMI [1x HDMI Uncompressed AV and Data]2x 3.5mm Stereo mini-jack [2x RS-232]2x 3.5mm Stereo mini-jack [2x Infra Red Receiver] Outputs 1x HDMI [1x HDMI Uncompressed AV and Data]2x RJ45 [2x HDMI & Propriety Data]2x 3.5mm Stereo mini-jack [2x Infra Red Emitter]1x RJ45 [1x Ethernet (I/O) IP] PSU 24V/2.7A Dimensions 145mm [W] x 30mm [H] x 178mm [D] Net Weight 540g Gross Weight 1.64kg Product Stock Category Core Product
Distribution
