T A PSD 3100 HV Pre-amplifier-Streaming-DAC (Titanium)

T A PSD 3100 HV Streaming DAC / Preamplifier / Streamer (Titanium) Key Features The T A PSD 3100 HV is an elite all-in-one digital front-end that combines a reference-class DAC, high-end preamplifier, and advanced streaming capabilities in a single HV-series chassis—engineered for purist audio performance and system simplicity. Triple-function design for maximum versatilityReference-grade D/A converter, high-end streamer, and fully balanced preamplifier in one integrated unit. Dual DAC architecture for native PCM and DSDQuadruple PCM converter (up to 32-bit / 768 kHz) and True 1-Bit DSD DAC (up to DSD1024) process each format natively with zero compromise. Built-in high-performance streaming platformSupports TIDAL, Qobuz, Deezer, Spotify Connect, internet radio, and UPnP/DLNA playback—all controlled via the T A MusicNavigator App. Comprehensive digital and analog connectivityIncludes asynchronous USB, AES/EBU, coaxial, optical, HDMI (ARC), and HV-Link, plus analog XLR and RCA outputs for flexible integration. Audiophile analog designFully discrete Class A output stages, relay-controlled volume and input switching, and ultra-low-noise circuitry ensure clean, dynamic sound. Advanced build quality and isolationEncased in a vibration-free, all-aluminum chassis with physically separated digital and analog sections for maximum signal integrity. Premium headphone amplifier includedFeatures a symmetrical Class A headphone output via 4.4 mm Pentaconn for private, high-resolution listening. Finished in titanium lacquer and built with absolute precision, the T A PSD 3100 HV Streaming DAC Preamplifier delivers exceptional sonic purity, digital flexibility, and control—all in a single, uncompromising component for high-end systems. Pre-amplifier-Streaming-DAC What does the term High-End mean in the year 2022? To what extent is music network-based in today’s world? These questions are answered by the PSD 3100 HV, which represents the first step into the world of the HV series multi-source streaming players. In every respect the PSD 3100 HV sets new standards for network-based music, whether it is its access to millions of pieces of music from the highest-quality streaming services, or from local networks with the new third-generation streaming client, or its two unique and exclusive con- verter architectures for DSD 512 and PCM 768 files, or its HV pre-ampli- fier topology and convenient integration in the T A MusicNavigator app. Construction Every T A device is developed with a single primary aim, the reproduction of music in as natural and uncoloured form as possible. In this aim the design of the D/A converter is of crucial importance, the tiniest negative influence, if not eliminated at this stage, inevitably exerts a seriously harmful effect on sound quality further down the line. We counter these potential losses with a series of ground-breaking in-house developments: de-jitter masterclo- cking, jitter reduction by a factor of four through the consistent separation (physical and topological) of the digital and analogue sections, and Path Separation Technology for separate PCM and DSD signals. The PSD 3100 HV is yet another impressive embodiment of our company maxim: pleasure in music brought to life by technology – Engineering Emotion. Streaming Our experience with streaming-capable equipment extends back to the year 2007, when we were the first High-End manufacturer with the courage to rethink digital music in a really consistent manner – by integrating streaming sources into our products. Over more than a decade of innovation we have evolved a global streaming architecture whose focal point is our streaming client. Its network-capable processor board handles a vast range of formats, acting as a bridge to the outside world. High-quality music reproduction from sources such as Tidal, Internet radio and even USB mass storage devices combine effortlessly with convenience and swift operation. The system provides the means of directly processing even DSD and PCM files in differing resolutions via the streaming client, and passing them on to the converters. Converters & Filters The PCM quadruple converter features a double symmetrical circuit with eight 32-bit BurrBrown converters, which correct non-linearities at an above-average standard, and reduce the already minimal residual noise by a further 6 dB. This converter delivers a level of resolution, dynamism, linearity and freedom from distortion which would be difficult to beat, even when dealing with critical passages and minute musical details. The converter is controlled by a 56-bit signal processor which offers various oversampling algorithms, giving the user the opportunity to fine-tune the system’s sound characteristics individually in terms of timing and frequency range. Four filter types are available; the Bezier filters developed by us in-house have optimum timing, and no trace of oscillation in the analogue signal. Our T A True 1-Bit DSD converter is also absolutely unique because it broke with convention: standard converters process DSD signals by converting them into PCM and reproducing them in PCM mode. In our opinion this process causes the innate quality of DSD recordings to be lost. We therefore developed the True 1-Bit DSD converter: this circuit handles the DSD data in native form rather than converting them, and completely retains the audible advantages of a bitstream. Connections & additional sources The PSD 3100 HV’s back panel reflects its versatile nature. Analogue input, aerial input, S/P-DIF, TOS Link, AES/ EBU, BNC, HDMI and USB inputs cover the full range of digital sources. Internet radio, as well as FM, FM-HD and DAB radio, are also present, and show that the PSD 3100 HV can effortlessly become the core of any High-End system, in which every source is able to unfold its maximum potential. Because it is not only an excellent strea- mer and D/A converter, but also a very excellent pre-amplifier. The input stages are discrete Class A preamps in HV technology, the volume control is relay-controlled with balance and loudness, its high-quality XLR and asym- metrical RCA outputs represent the signal bridge to power amplifiers and active loudspeakers, while headpho- nes can be connected via a symmetrical 4.4 mm Pentaconn headphone output can be connected.
