– TRANSMIT THE 2 CHANNEL AND 8 CHANNEL BALANCED AUDIO SIGNAL 2 Channel Model: ITX/IRX-102, 2 channel balanced audio signal transmission 8 Channel Model: FTA/FRA/ITX/IRX-108, 8 channel balanced audio signal transmission – THE SOLUTION OF SENDING A SOUND SOURCE IN LONG DISTANCE Optical Cable Communication [FTA/FRA-108S] : Sending a signal in long distance normal 24km(maximum 28km) UTP Cable Communication [ITX/IRX-108(102)] : Sending a signal in long distance (maximum 150m) – HIGH QUALITY AUDIO SIGNAL It sends the digital signal converted to 24Bit, 48kHz to provide the high quality audio signal (higher than S/N 90dB, less than THD 0.01%) – AC/DC SUPPORTS It responses to the field conditions with supporting AC and DC power input terminals – INPUT SENSITIVITY CONTROL FUNCTION THROUGH PAD SWITCHES If it is clipped due to high input audio signal level, push the PAD switch to decrease the input signal in 10dB – INPUT SIGNAL DISPLAY Detects the audio signal and clip approved to each channel and display on the front panel. – RS-232/RS-422/CONTACT POINT DATA RECEIVING/SENDING (OPTION MODULE) The optional module (CT-100M/CR-100M) can be installed to make a possible to receive and send a RS-232, RS-422 and 8 channel contact point data.
