SBS KT-HD91 PTZ Camera

PTZ Camera Features 1080P HD Resolution: HD91A: Apply SONY 1/2.8” Progressive CMOS sensor, 2.07 Megapixels, can reach max.1920×1080 high resolution with a frame rate up to 60fps. HD91R: Apply SONY 1/2.8” Progressive CMOS sensor, 2.07 Megapixels, can reach max.1920×1080 high resolution with a frame rate up to 60fps.   Abundant Outputs: Support HDMI, 3G-SDI, LAN, USB3.0 HD 1080P output in sync.   Ultra High Frame Rate: video output frame rate can reach 1080P 60fps.   Optical zoom can choose: HD91A: 20x optical zoom 16x digital zoom HD91R: 12x optical zoom 16x digital zoom   Low Light: Brand new CMOS image sensor with ultra-high S/N Ratio can effectively reduce image noise in low light conditions. Applying 2D&3D Digital noise reduction at the same time, reduces image noise significantly, even in ultra-low light conditions, could remain the frame clean and clear, S/N Ratio of the image is higher than 55dB. Remote Control: Use RS232, RS422/RS485 serial ports to control multiple cameras with a daisy chain.   The signal transparent transmission function of the infrared remote controller: Apart from receiving its own infrared remote controller’s signals, it can also receive alerts of the consumer’s infrared remote controller and send them to the video conference terminal via VISCA IN port.   Multi-installation Methods: Wall mounting, desktop or ceiling mounting.   Camera Resolution 1080p60/50, 1080p59.94/29.97, 1080p30/25, 1080i60/50, 1080i59.94, 720p60/50 Image Sensor SONY 1/2.8” Progressive CMOS Scan Mode Line by line Lens HD91A 20X optical zoom, f=5.2mm(w)~104mm(f)HD91R 12X optical zoom, f=3.9mm(w)~46.8mm(f) Focus System Auto/Manual Minimum Illumination 0.5 Lux @ (F1.8, AGC ON) Shutter Speed 1/25s~1/10000s White Balance Auto/Manual/One-click/Indoor/Outdoor BacklightCompensation Support Digital NoiseReduction 2D&3D Digital noise reduction S/N Ratio ≥55dB Horizontal View Angle HD91A 58.7°(W)～3.2°(T)HD91R 72.5°(W)～6.5°(T) Vertical View Angle HD91A 33°~1.8°HD91R 40.8°~3.7° Horizontal Rotation  Range 355° Vertical Rotation  Range -30°~ 90° Horizontal Rotation Speed Range 1°~90°/s Vertical Rotation Speed Range 1°~90°/s Electronic Flip Support Image Freeze Support POE Power Supply 802.3af(optional) Preset Position 9 preset positions by IR remote controller, 200 preset positions by joystick controller or PC Accuracy of Preset Position 0.1°±10% USB Features Protocol UVC1.1, UAC1.0 Operating System Window7 and above, MacOS, Linux, Android UVC Video Coding Format YUY2, MJPEG, H.264, H.265 UVC Video Resolution 320×240, 640×480, 720×576, 800×600, 1280×720, 1920×1080, 3840×2160 and so on UVC Video Frame Rate Max.60 Network Characteristics Code Stream Main code stream*1, Auxiliary code stream*1 Coding Format H.264, H.265, MJPEG Streaming Media Protocol RTMP, RTSP, RTMPS, ONVIF, SRT, NDI|HX(optional) Main Code Stream Resolution 576P30, 720P25, 720P30, 1080P25, 1080P30, 2160P25, 2160P30 Auxiliary Code Stream Resolution 576P30, 720P25, 720P30 Interface Video Output HD 1 Line, HDMI: Version1.41 Line, 3G-SDI: SMPTE-274M(Level A), SMPTE-296M USB Interface 1 Line, USB 3.0, Type-B Socket Network Interface 1 Line, RJ45: 10M/100M Ethernet port Other Input 1 Line, Line In, 3.5mm AUDIO-IN Control Mode 1 Line, RS232 IN: 8 Pin Mini Din, up to 30 meters, VISCA/Pelco-D/Pelco-P Protocol 1 Line, RS232 OUT: 8 Pin Mini Din, up to 30 meters, VISCA/Pelco-D/Pelco-P Protocol 1 Line, RS422/485 IN/OUT: Nine-core Phoenix Interface, up to 1200 meters, VISCA/Pelco-D/Pelco-P Protocol Power Interface DC 12V IEC60130-10(JEITA Standard RC-5320A) TYPE4 General Specifications Input Voltage DC 12V Input Current Max.1.0A Power Consumption Max.12W(DC 12V Operating Temperature 0~40℃ Storage Temperature -10-60℃ Camera Dimensions (L)161×(W)133×(H)181mm Color Black Weight 1200g Accessories DC 12V power adapter, IR Remote, Operation manual, RS-232C Cable, HDMI Cable, USB Cable, Ceiling bracket (Wall bracket optional) [/vc_column_text][/vc_column][/vc_row]
