HDMI 2.0, DisplayPort 1.4, and DVI 1.0 compliant HDCP 1.x and 2.2 compliant HDMI, 1 Mini DisplayPort, and 1 USB Type-C input Supports up to 4K UHD (18Gbps, 4K@60Hz 4:4:4, 8-bit) video input and output Supports 10-bit and 12-bit HDR (High Dynamic Range) input/output Supports pass-through of many audio formats including 8 channel LPCM, Bitstream, and HD Bitstream Supports auto-switch functionality with a “last memory” feature EDID bypass with an optimized algorithm to ensure optimal resolution and feature support Easy to read LEDs to indicate input selection and operational mode Powered via the Mini-USB port (1.2 Amps required) Small and portable switch box design Inputs 1x HDMI [1x HDMI Uncompressed AV and Data]1x USB-C [1x USB-C USB-C / Thunderbolt]1x Display Port [1x Mini DP Uncompressed AV] Outputs 1x HDMI [1x HDMI Uncompressed AV and Data] PSU 5V/1.2A USB Dimensions 85mm [W] x 26mm [H] x 85mm [D] Net Weight 100g Gross Weight 360g Product Stock Category Special Order
