HDMI 1.3 and DVI 1.0 compliant Supports resolutions up to and including 1080p @ 60Hz, 4K x 2K @ 24/30Hz and 1920x1200 60Hz (WUXGA) Supports up to 16-bit Deep Colour HD Audio Support : LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS HD Master Audio (Sampling rates from 32 kHz to 192 kHz) Supports four different EDID modes: Read / Write / Emulate / Bypass modes Read Mode: Reads the TV/display’s EDID information Write Mode: Overwrites the TV/display’s EDID information (TV/display needs to be able to support overwrite function) Emulator Mode: Allows the source device to read the selected EDID information from the unit’s default or learnt EDID memory Bypass Mode: Allows the source device to read the EDID information from the TV/display directly 8 unique sets of EDID settings may be stored via the learning procedure. Can be powered via USB or HDMI input Supports DVI sources when used with a DVI to HDMI adaptor (not supplied) Supports CEC functionality PSU USB powered Dimensions 71mm [W] x 23mm [H] x 65mm [D] Net Weight 120g Gross Weight 240g Product Stock Category Core Product
