PUV-C3050TX-UA – HDBaseT3 Full 4K USB-C Transmitter with USB, PoH, Audio Pathway & HDMI bypass

USB-C (USB 3.0) video compatible HDMI 2.0 and DVI 1.0 compatible HDCP 2.2 and HDCP 1.x compliant HDBaseT 3.0 compliant (Backwards compatible with HDBaseT 2.0/1.0) 1 x USB-C input; 1 x HDBaseT3 and HDMI output Supports up to 4K UHD (18Gbps, 4K@60Hz 4:4:4, 8-bit) video output over both HDMI and HDBaseT Supports Deep Color input and output up to 12-bit Supports CEC bypass HDBaseT extends video, audio and data over a single Cat.6A/7 cable and can reach distances up to 70m/230ft HDBaseT feature support: HD Video and Audio, PoH (PSE), Bi-directional audio (analogue), and Control (bi-directional USB/IR/RS-232 pass-through) Supports 10-bit and 12-bit HDR (High Dynamic Range) input/output 2 USB 2.0 Type-A device ports and 1 USB-C host port Selectable USB-C audio extraction/analog audio bypass functionality when paired with a compatible receiver Note: USB-C audio extraction is only available with LPCM 2.0 sources. HDMI output functions as a local monitor Can supply PoH to a connected compatible receiver Inputs 1x USB-C [1x USB-C / Thunderbolt]1x Phoenix (3 pin) [1x Analogue Stereo (L/R) Audio Input]2x USB Type A [2x Propriety Data]1x Phoenix (4 pin) [1x Shared IR I/O] Outputs 1x RJ45 [1x HDBaseT3 HDMI & Propriety Data]1x HDMI [1x HDMI Uncompressed AV and Data]1x Phoenix (3 pin) [1x Analogue Stereo (L/R) Audio Output] PSU 24V/2.7A Dimensions 128mm [W] x 25mm [H] x 108mm [D]  Net Weight 420g Gross Weight 1.34kg Product Stock Category Core Product
