HDMI input and output supports up to 4K@60Hz with HDR bypass HDCP 2.2 and HDCP 1.x compliant Note: Video capture of sources using HDCP encryption is not supported USB 3.0 connection allows uncompressed video and audio data capture (up to 4K@30Hz, LPCM 2.0) Note: 4K sources with framerates higher than 30Hz are automatically converted to 4K@30Hz for USB capture 2 additional analog audio inputs via 3.5mm ports (1 x Stereo & 1 x Microphone) Supports capture of stereo audio from the HDMI input (LPCM 2.0) as a part of the primary stream, as well as audio from one or both of the analog audio inputs as a secondary audio stream Integrated audio mixer provides a way to combine the line and mic analog audio inputs Complies with the UAC (USB Audio Class) and UVC (USB Video Class) standards, allowing the unit to support most common capture and video streaming software Note: Access to many of the software controllable features of the unit, beyond simple video capture, requires the use of the USB Video Capture Control software which is only available for Windows 10 or later PCs Supports video timing stabilization to help ensure a reliable and stable USB capture stream Unit may be powered directly via USB-C connection (USB3.0) Supports the Free OBS (Open Broadcaster Software) streaming software which is available for Windows 10 (or later), macOS, and Linux Inputs 1x HDMI [1x HDMI Uncompressed AV and Data]1x 3.5mm Stereo mini-jack [1x Analogue Stereo(L/R)]1x 3.5mm Stereo mini-jack [1x Microphone] Outputs 1x HDMI [1x HDMI (bypass) Uncompressed AV and Data]1x USB-C [1x USB-C / Thunderbolt] PSU USB powered Dimensions 84mm [W] x 23mm [H] x 113mm [D] Net Weight 180g Gross Weight 380g Product Stock Category Core Product
