HDMI input and output with HDR, 3D & 4K@60Hz support, DVI 1.0 compatible HDCP 2.2 and HDCP 1.x compliant Supports up to 4K UHD (18Gbps, 4K@50/60Hz 4:4:4, 8-bit) video input and output Supports Deep Colour input and output up to 12-bit Supports 10-bit and 12-bit HDR (High Dynamic Range) input/output Automatically scales 4K sources to 1080p for USB capture Unit may be powered directly via USB 3.0 (When using USB 2.0, a Y-cable is required to provide additional power) Supports video timing stabilization to help ensure a reliable and stable USB capture stream Capturing over USB 3.0 allows uncompressed video and audio data capture (up to 1080p, LPCM 2.0) Capturing over USB 2.0 requires the application of minimal MJPEG compression to the video and audio data (up to 1080p, LPCM 2.0) Supports capturing 2 channel digital audio from either HDMI (LPCM 2.0) or the 3.5mm analog audio input (selectable via configuration software) Compliance with the UAC (USB Audio Class) and UVC (USB Video Class) standards, allows the unit to support most common capture and video streaming software Note: Availability and access to the controllable features of the unit depend on the capture software used Support for the Free OBS (Open Broadcaster Software) streaming software which is available for Windows PC, macOS and Linux Inputs 1x USB 3 Type B [1x Power & Data]1x HDMI [1x HDMI Uncompressed AV and Data]1x 3.5mm Stereo mini-jack [1x Analogue Stereo(L/R)] Outputs 1x HDMI [1x HDMI Uncompressed AV and Data]1x USB 3 Type B [1x Stream data Power & Data] PSU USB powered Dimensions 128mm [W] x 25mm [H] x 108mm [D] Net Weight 360g Gross Weight 600g Product Stock Category Core Product
