Beskrivelse AJA ROI-SDI 3G-SDI to HDMI/3G-SDI Scan Converter AJA ROI-SDI 3G-SDI to HDMI/3G-SDI Scan Converter, features: Scan Converter 3G-SDI input with loop through 3G-SDI and HDMI 1.4 outputs Supports SD, HD, and 3G formats (see Tech Specs for complete list) Region of Interest scaling Up, down, cross-conversion Aspect ratio conversion Frame rate conversion Image H/V flip and 90 degree rotation Supports 8-channels of embedded audio 2-channel analog audio output of disembedded audio Sync reference selection (External, or Free-run) Configure via USB port and supplied Mini-Config software Uses 5-18VDC power (universal power supply included) Five year warranty Video Input Formats (HD) 1920 x 1080i 50, 59.94 (HD) 1920 x 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 (HD) 1280 x 720p 50, 59.94, 60 (SD) 625i, 50 (SD) 525i, 49.94 Video Output Formats (HD) 1920 x 1080p 50, 59.94, 60, SMPTE 425-1 Level A mapping structure 1 (4:2:2 10-bit YCbCr) (HD) 1920 x 1080p 23.98, 24, 25, 29.97, 30 (HD) 1920 x 1080i 50, 59.94, 60 (HD) 1280 x 720p 50, 59.94, 60 (SD) 625i 25 (SD) 525i 29.97 Color Range Full SMPTE Reference Source Free Run Ext Ref Reference Input Supported reference video inputs include: 1080i tri-level sync 1080p tri-level sync 720p tri-level sync 625i Color Black 525i Color Black 75 ohm terminating Video Input 1x 3G-SDI BNC, SMPTE-259/292/424 Video Outputs 1x 3G-SDI BNC, loop through 1x 3G-SDI BNC, SMPTE-259/292/424 1x HDMI Type A, HDMI v1.4 HDCP ROI does not encode the HDMI output with HDCP encryption Audio Output Digital SDI embedded audio, 24-bit, 8-Channel HDMI embedded audio, 24-bit, 2-Channel or 8-Channel Audio Output Analog 2x Analog RCA Jack, 2-Channel User controls USB port used with supplied cable and Mini-Config software application to configure device via Mac or Windows Size (w x d x h) 5.77″ x 4.02″ x 0.9″ (146.56 x 102.11 x 22.86 mm) Weight 0.6 lb (0.3 kg) Power Uses AJA power supply model DWP-U-R1 (included with purchase) 100-240V, 50/60 Hz universal input 5-20V DC regulated, 7 watts max Environment Safe Operating Temperature: 0 to 40 C (32 to 104 F) Safe Storage Temperature (Power OFF): -40 to 60 C (-40 to 140 F) Operating Relative Humidity: 10-90% noncondensing Operating Altitude: <3,000 meters (<10,000 feet) Endringer i teknisk spesifikasjon kan forekomme. Teknisk spesifikasjon fra leverandør: AJA Kontakt oss gjerne for spørsmål om våre produkter. Vi hjelper deg med å velge de rette tekniske løsningene for din bedrifts behov. Du kan kontakte vårt salgsteam direkte ved å sende e-post til
