Description The UWB-7 ultra-wideband omnidirectional antenna is a wideband patch antenna suitable for omnidirectional radio signal transmission and reception, signal coverage, and broadband signal testing. The antenna covers frequencies commonly used by RF components such as mobile communications, UWB positioning modules, and Wi-Fi. Specifications: Antenna impedance: 50 ohms Power handling: 15 W Frequency range: 700 MHz–9 GHz Gain: 3.5 dBi VSWR: 2 (typ.) Connector type: SMA-K (female, external thread, internal bore) UWB-7 0.7G Directivity Pattern UWB-7 2.1G Directivity Pattern UWB-7 VSWR UWB-7 S11 UWB-7 Total Radiation Efficiency
